HK42FZ013 Carrier Furnace Control Board – CEPL130438-01

HK42FZ013 Carrier Furnace Control Board – CEPL130438-01 | CEBD430438-06A SS-01L | OEM Integrated Furnace Control (IFC) Board | Tested Condition: Used – Clean, Tested & Fully Functional Availability: Ready for pickup / Fast response Key Specifications Manufacturer: Carrier OEM Part Number: HK42FZ013 Barcode Part Number: HK42FZ0132406 PCB Number: CEPL130438-01 B Board Number: CEBD430438-06A SS-01L Image Label: F30CU Component Type: Integrated Furnace Control (IFC) Board Ignition System: Automatic Ignition System Voltage: 24VAC Frequency: 60Hz Control Rating: 465mA Certification: ANSI Z21.20 Fuse: 3 Amp Automotive Blade Fuse (fuse missing) Terminal Connections Thermostat / Low Voltage Terminals 5-screw thermostat terminal block: R – 24VAC Power C – Common W – Heat Call Y – Cooling Call G – Fan Control Transformer / Accessory Connections SEC-1 SEC-2 HUM – Humidifier Output Line Voltage Connections L1 – Line Voltage Input L2 – Neutral EAC-2 – Electronic Air Cleaner Neutral NEUTRAL BLW – Blower Neutral Terminals Harness / Diagnostic Connections PL1 – Main Harness Connector TEST/TWIN – Diagnostic Testing / Furnace Twinning Multiple multi-pin harness connectors Blower Control Features Adjustable Blower Off Delay Selectable jumper settings: 90 Seconds 120 Seconds 150 Seconds 180 Seconds Allows adjustment of blower operation after heat call termination. Major Components Relays Potter & Brumfield T7CS5D2-12 Coil: 12VDC Contacts: 5A @ 120VAC Tyco Electronics / Potter & Brumfield Relays Heavy-duty blower and load switching relays Potter & Brumfield T77V1D10-12 Coil: 12VDC Rating: 10A @ 120VAC 10A @ 30VDC Resistive Additional Components Large ceramic power resistor Two main control microprocessors STMicroelectronics IC Red STATUS CODE LED 3A fuse holder Jumper-select blower timing control Features ✔ Genuine Carrier OEM furnace control board ✔ Automatic ignition system control ✔ Controls heating, cooling, and blower operation ✔ Adjustable blower off-delay settings ✔ Built-in diagnostic status LED ✔ TEST/TWIN capability ✔ Humidifier output ✔ OEM replacement quality Compatibility Direct replacement numbers: HK42FZ013 HK42FZ0132406 CEPL130438-01 CEBD430438-06A SS-01L Commonly used in select: Carrier furnaces Bryant furnaces Payne furnaces ⚠️ Verify before purchase: Furnace model number Connector arrangement Board revision Terminal layout Why Buy This One? ✔ Exact Carrier OEM replacement ✔ Multiple searchable part numbers included ✔ Common Carrier family furnace board ✔ Adjustable blower timing ✔ Tested and ready for installation Pickup Toronto / GTA
