DLS CA22 2-Channel Amplifier 2 x 60 Wats RMS @ 4 ohm

DLS CA22 2-Channel Amplifier 2 x 60 Wats RMS @ 4 ohm. CA 22 is a powerful amplifier with a power output of 2 x 60 Watts. With a mono bridge-connection, it puts out all of 200 Watts. Built-in low-pass filter for subwoofers, variable between 50 and 500 Hz. The high-pass filter is variable between 15 and 500 Hz. Built-in protection circuits shut down the amplifier in the event of overloads. High level input with AUTO-start function makes it easier to connect to factory installed head units. - RMS output power @ 13,8 V, 20Hz - 20 kHz Number of channels2 Amplifier classAB Typical power in 4 ohm2 x 60 W Typical power in 2 ohm2 x 100 W Mono bridge mode 4 ohm200 W Damping factor>100 S/N ratio, A-weighted>100 dB Frequency range10 Hz - 35 kHz Input sensitivity0,25 - 5 V Input impedance>10 kohm Input impedance, high level100 ohm High pass filter15-500 Hz Low pass filter50 - 500 Hz Low level output1 High level input with auto start1 Power consumption (idle)0,5 A Power consumption (max)25 A Rec. power cableMinimum 5AWG / 16 mm2 Fuses1 x 25 A Dimension (W x D x H)70 x 230 x 268 mm / 2,92 x 9,06 x 10,55" Weight2,7 kg / 5,95 lb
