1097-610 Automatic Spark Ignition Control Board

1097-610 Automatic Spark Ignition Control Board – 24VAC | ANSI Z21.20 | Furnace Ignition Module | Tested Condition: Used – Clean, Tested & Fully Functional Availability: Ready for pickup / Fast response Key Specifications Board Number: 1097-610 Revision / Printed Code: 0932 Component Type: Automatic Spark Ignition Control Board System Rating: 24VAC, 50/60Hz Maximum Current: 0.5A Ignition Type: Spark Ignition Certification: ANSI Z21.20 Automatic Ignition System Fuse: 3 Amp Automotive Blade Fuse (F1) Thermostat & Low-Voltage Connections P2 Thermostat Connector: R – 24VAC Power W1 – First Stage Heat Y – Cooling C – Common G – Indoor Blower W2_OUT – Second Stage Heat Output Additional Connections: CMB_BLWR – Combustion Blower CMB_L – Combustion Line FLAME – Flame Sensor GROUND 24VAC – Control Power 6-Pin Molex Harness Connector Major Components Potter & Brumfield T7CS5D2-24 Relay 24VDC Coil 5A @ 120VAC Potter & Brumfield T7CS1D2-12 Relay 12VDC Coil 5A @ 120VAC Heavy-duty blower control relay High-voltage spark ignition transformer/coil Transformer / Inductor: 704-B2-2REU 09311 ALF GCI 0892 Dual microcontroller ICs High-power resistor network Replaceable 3A automotive blade fuse Features Automatic spark ignition control Electronic flame monitoring Combustion blower control Two-stage heating support (W1 / W2_OUT) Integrated flame sensor circuit Built-in ignition transformer Replaceable 3A fuse for circuit protection Compatibility Suitable for select: Residential Gas Furnaces Unit Heaters Commercial Heating Equipment Spark Ignition Systems ⚠️ Before purchasing, verify: Board number (1097-610) Connector locations Ignition type Furnace model Terminal configuration Applications Gas Furnace Ignition Systems Automatic Spark Ignition Burner Management Controls Combustion Blower Control HVAC Heating System Repairs Why Buy This One? ✔ Genuine OEM ignition control board ✔ Supports single-stage and two-stage heating systems (W1 / W2_OUT) ✔ Built-in spark ignition transformer ✔ Premium Potter & Brumfield relays ✔ Replaceable 3A fuse for easy servicing ✔ Tested and ready for installation Pickup Toronto / GTA
