Graphic card GTX 770

Built on the 28 nm process, and based on the GK104 graphics processor, in its GK104-425-A2 variant, the card supports DirectX 12. Even though it supports DirectX 12, the feature level is only 11_0, which can be problematic with newer DirectX 12 titles. The GK104 graphics processor is an average sized chip with a die area of 294 mm² and 3,540 million transistors. It features 1536 shading units, 128 texture mapping units, and 32 ROPs. NVIDIA has paired 2,048 MB GDDR5 memory with the GeForce GTX 770, which are connected using a 256-bit memory interface. The GPU is operating at a frequency of 1046 MHz, which can be boosted up to 1085 MHz, memory is running at 1753 MHz (7 Gbps effective). Being a dual-slot card, the NVIDIA GeForce GTX 770 draws power from 1x 6-pin + 1x 8-pin power connector, with power draw rated at 230 W maximum. Display outputs include: 2x DVI, 1x HDMI 1.4a, 1x DisplayPort 1.2. GeForce GTX 770 is connected to the rest of the system using a PCI-Express 3.0 x16 interface. The card's dimensions are 267 mm x 111 mm x 38 mm, and it features a dual-slot cooling solution. Its price at launch was 399 US Dollars.
